主要技术规格
PRIMARY TECHNICAL SPECIFICATIONS
|
||
|
机型
Type
|
304 | |
|
整机驱动型式
Driving Type
|
四轮驱动
4WD
|
|
|
挡位数 (前进/后退)
Number of Shift
|
8+2 | |
|
发动机标定功率 (kW)
Rated Power of Engine
|
22.1 | |
|
动力输出轴功率 (kW)≥
Power of PTO
|
18.8 | |
|
最大牵引功率 (kW)≥
Max. Traction Power
|
16.6 | |
|
最大牵引力 (kN)≥
Max. Traction Force
|
8.4 | |
|
外形尺寸
(mm)
Overall Dimentions
|
长 Length | 2870 |
| 宽 Width | 1400 | |
| 高 Height |
2050 至排气管顶
To end of the exhaust pipe
|
|
|
轮距(mm)
Tread
|
前轮 Front Tire | 1200、1300 |
| 后轮 Rear Tire | 1200、1300 | |
|
轴距(mm)
Wheel Base
|
1627 | |
|
最小离地间隙(mm)
Ground Clearance
|
292 | |
|
最小使用质量(kg)
Min. Eunning Weight
|
1360 | |
|
配重质量(kg)
Mass of Balance
|
前配重 Front Balance | 0/72 |
| 后配重 Rear Balance | 70 | |
|
标配轮胎规格
Type of Tire
|
6.00-16/11.2-24 | |
|
拖拉机理论速度(km/h)
Theory Speed of Tractor
|
||
| 前进低挡 Forward Low Shift | 1.77、2.24、3.65、5.78 | |
| 前进高挡 Forward high Shift | 7.55、9.53、15.52、24.62 | |
| 后退 Reverse | 1.63、8.16 | |
