主要技术规格
PRIMARY TECHNICAL SPECIFICATIONS
|
||
|
机型
Type
|
504 | |
|
整机驱动型式
Driving Type
|
四轮驱动
4WD
|
|
|
挡位数 (前进/后退)
Number of Shift
|
8+2 | |
|
发动机标定功率 (kW)
Rated Power of Engine
|
36.8 | |
|
动力输出轴功率 (kW)≥
Power of PTO
|
31.3 | |
|
最大牵引功率 (kW)≥
Max. Traction Power
|
27.6 | |
|
最大牵引力 (kN)≥
Max. Traction Force
|
12.2 | |
|
外形尺寸
(mm)
Overall Dimentions
|
长 Length | 3600 |
| 宽 Width | 1590 | |
| 高 Height |
2420至安全架顶
To top of protective frame
|
|
|
轮距(mm)
Tread
|
前轮 Front Tire | 1300 |
| 后轮 Rear Tire | 1300 | |
|
轴距(mm)
Wheel Base
|
1950 | |
|
最小离地间隙(mm)
Ground Clearance
|
375 | |
|
最小使用质量(kg)
Min. Eunning Weight
|
1980 | |
|
配重质量(kg)
Mass of Balance
|
前配重 Front Balance | 72/84 |
| 后配重 Rear Balance | 70/140 | |
|
标配轮胎规格
Type of Tire
|
8.3-20/12.4-28 | |
|
拖拉机理论速度(km/h)
Theory Speed of Tractor
|
||
| 前进低挡 Forward Low Shift | 2.31、3.11、4.28、6.39 | |
| 前进高挡 Forward high Shift | 9.67、13.03、17.90、26.74 | |
| 后退 Reverse | 2.21、9.48 | |
| 指定AL-AMIN SH为乌兹别克市场经销商 | ||
| appointed AL-AMIN SH as the distributor for the Uzbek market. | ||
